1000 KVA Pad Mounted Transformer
03-11 2025 | By:
Primary Voltage:7.2KV/11KV/13.2KV/ 13.8KV/34.5KV/46KV Or Others
Secondary Voltage:208Y/120 V to 14,400 V Or Others
CONNECTION TYPE: Dyn11/YNyn0 or others
Standards: ANSI/IEEE, CSA/CAN, DOE
Power Rating: 100 kVA, 8 MVA
1000 KVA Pad Mounted Transformer Customized
| 75KVA-2500KVA OIL TRANSFORMER | ||||||
|---|---|---|---|---|---|---|
| Rated Cap acity(kVA) | High Voltage(v) |
Low Voltage(v) |
Connection Symbol |
Standard | Short-circuit impedance(%) |
Efficiency（%） |
| 75 | 4160 7200 12000 12470 13200 13800 19920 24940 34500 |
110 220 230 400 480 |
Delta-Wye Dyn1 Ynyn0 |
IEEE /ANSI /DOE |
4-7% | 99.03 |
| 112.5 | 99.11 | |||||
| 150 | 99.16 | |||||
| 225 | 99.23 | |||||
| 300 | 99.27 | |||||
| 500 | 99.35 | |||||
| 750 | 99.4 | |||||
| 1000 | 99.43 | |||||
| 1500 | 99.48 | |||||
| 2000 | 99.51 | |||||
| 2500 | 99.53 | |||||
1000 KVA Pa Mount Transformer
-
- 13.8kV Outdoor Pad-Mounted Transformer
-
- Padmount Transformers
-
- 500 kVA Padmount Transformers
ZTELECGRUOP transformer has customized an optimal 3-phase 1000 KVA pad mounted transformer for a US client, with a voltage rating of up to 34.5KV. This transformer utilizes a star connection (Y connection) and complies with the International Electrotechnical Commission (IEC) standard IEC60076, boasting excellent design and outstanding performance. Crafted meticulously by EverNew, this tailored 3 phase 1000 KVA pad-mounted transformer integrates cutting-edge technology with specific client requirements, ensuring a stable and reliable power supply. It serves as a robust support for the development and operation of urban power grids.The ZGS11 series combined transformer is a new type of distribution equipment. It features compact size and rational structure. Specifically designed for load-centered urban power grids, the combined transformer reduces energy consumption and improves power supply quality. Most importantly, this series of products has been widely applied in communities, public places, and industrial and mining enterprises across the country. Product Features:
The fully sealed insulation structure ensures personal safety.
It is applicable not only for ring networks but also for terminals.
Low loss, low noise, and superior performance.
Low temperature rise, high overload capacity.
The transformer adopts a special structure, highlighting its high quality.
1000 Kva Pad Mounted Transformer Applicable Standards
IEEE Std C57.12.00 – Standard for Standard General Requirements for Liquid-Immersed Distribution, Power, and Regulating Transformers.
IEEE Std C57.12.28 – Pad-Mounted Equipment – Enclosure Integrity.
IEEE Std C57.12.34 – Standard Requirements for Pad-Mounted, Compartmental-Type, Self-Cooled, Three-Phase Distribution Transformers
IEEE Std C57.12.90– Standard Test Code for Liquid-Immersed Distribution, Power, and Regulating Transformers and IEEE Guide for Short-Circuit Testing of Distribution and Power Transformers.
IEEE Std C57.12.91 – Guide for Loading Mineral-Oil-Immersed Transformers.
Installation of EverNew 1000 KVA Pad Mounted Transformer
For outdoor electrical installations, the 1000 KVA Pad Mounted Transformer serves as a reliable solution. Typically placed on a sturdy base, it is installed within a tank made of low carbon steel or stainless steel, featuring two doors and a secure locking mechanism.
Designed specifically to withstand outdoor conditions, the 1000 KVA Pad Mounted Transformer can operate in temperatures up to 30 degrees Celsius and at altitudes of up to 1000 meters. Its robust structure ensures durability and adaptability to various weather conditions.
The installation process involves carefully positioning the transformer on its base to ensure stability and secure attachment. The tank provides protection from environmental factors, while the doors allow for easy access when maintenance is required.
ZTELECGRUOP is a leading manufacturer of 1000 KVA Pad Mounted Transformer in China. We offer installation guidance services for 1000 KVA Pad Mounted Transformer. Contact us to have our technical service team assist you.
Packaging of 1000 KVA Pad Mounted Transformer
Ensuring the safety of our 1000KVA Pad Mounted Transformer during transportation is paramount. ZTELECGROUP employs sturdy standard wooden boxes for packaging, engineered to withstand transportation rigors and protect transformers from damage or misuse. Our commitment to quality extends from product design to delivery, prioritizing customer satisfaction and peace of mind.
At ZTELECGROUP Transformer, we understand the importance of transportation security for sensitive electrical equipment. That’s why we ensure our packaging solutions offer maximum protection, allowing customers to receive transformers in pristine condition. Contact EverNew for reliable transformer supply and transportation security.
Schematic Diagram of 1000 KVA Pad Mounted Transformer
Explore the complex internal structure of a 1000 KVA Pad Mounted Transformer, carefully annotated to highlight its various components and structure. From the core and windings to the bushings and cooling systems, every aspect of a transformer’s design is critical to its efficient operation in a power distribution system.
ZTELECGRUOP Transformer moves from schematics to practical applications, providing comprehensive end-to-end services from product design to delivery. EverNew is committed to excellence and innovation, ensuring that each transformer is not only designed to perfection, but also rigorously tested to meet the highest quality standards. From initial concept to final installation, EverNew Transformer provides a seamless journey to deliver reliable, efficient power solutions for modern power infrastructure.
